FineCut8 for CorelDRAW Ver8.7.6 Upgrade

种类	Software
版本	8.7.6
公开日	2018年08月30日
适用OS	Windows 7 Windows 7 (32bit) Windows 7 (64bit) Windows 8.1 Windows 8.1 (32bit) Windows 8.1 (64bit) Windows 10 Windows 10 (32bit) Windows 10 (64bit)
备注	CorelDRAW® Graphics Suite 11/12/X3/X4/X5/X6/X7/X8/2017/2018 English/German/Italian/French/Portuguese/Spanish/Russian/Simplified Chinese/Traditional Chinese CorelDRAW® Technical Suite X6/X7/2017/2018 English/German(X7 or later)/French(X7 or later)
	FineCut8 for CorelDRAW

---

About this Upgrade software

This Upgrade software requests older version of Mimaki FineCut CD-ROM while installation.

The following functions have been change

[Ver8.7.5 -> Ver8.7.6]
- Newly supported application -

1. CorelDRAW GraphicsSuite 2018 is supported.
2. CorelDRAW TechinicalSuite 2018 is supported.

- Improved function -

1. In CFL-605 RT, square register marks can be created and confirmed.
   You can use it by applying CFL-605 RT FW Ver 1.70.

[Ver8.7.4 -> Ver8.7.5]

- Improved function -

1. ID cut has bee supported in CFL-605 RT.
2. Mark separation function has been supported in CF22-1225.

- Fixed bugs -

1. When trying to detect a register mark in the direction that is not a separation direction at using intermediate register mark, it did not work properly. (Corel only)

[Ver8.7.3 -> Ver8.7.4]

- Improved function -

1. In CF22-1225, RasterLink output can be now used.
2. When recognizing register marks, head withdrawal function can be now used after cutting. (CJV30 series, TPC, CVJ150/300 series, UCJV150/300 series)

- Fixed bugs -

1. When doing ID cutting the data containing stroke width, the printing shifted.(Corel only)
2. In CF22-1225, favorites could not be registered and applied normally.
3. For CrelDRAW X7, Tips of FineCut menu icon was displayed in French even it had to be in German.(Corel only)

[Ver8.7.2 -> Ver8.7.3]
- Fixed bugs -

1. When outputting ID cut after expanding / decreasing in size, the cut shifts incorrectly.

[Ver8.7.1 -> Ver8.7.2]
- Newly functions -

1. Mimaki UCJV300/150 series is now supported.

[Ver8.7.0 -> Ver8.7.1]
- Newly functions -

1. PDF is added to ID cut output format (print data).
   Print data format can be selected and outputted from EPS / PDF.

[Ver8.6.4 -> Ver8.7.0]
- Newly functions -

1. CF22-1225 is supported.
2. ID cut function is installed. (CF22-1225)
   When a printer prints data with ID and a cutting plotter detects the ID, it can cut automatically by the function.
   To do the ID cut, set the cutting condition with FineCut first and output the ID cut data.
   And print register marks with the given ID with RasterLinkPlus.
   Then, detect the register marks with the cutting plotter.

   Conditions for using ID cut:
   • RasterLink 6 Plus ver1.2 or higher, and CuttingLink ver 1.0 or higher are required.

[Ver8.6.3 -> Ver8.6.4]
- Newly functions -

1. CorelDRAW 2017(32/64bit) is now supported.

[Ver8.6.2 -> Ver8.6.3]
- Newly functions -

1. Simultaneous frame extraction
   Outer and inner frames are simultaneously extracted using the frame extraction function.

[Ver8.6.1 -> Ver8.6.2]
- Newly functions -

1. Tool name of output condition can be set （Only for CFL-605RT FW Ver1.50 or later）
   Tool can be set by tool name in addition to current pen number from No1 to No 6.

[Ver8.6 -> Ver8.6.1]
- Newly functions -

1. CorelDRAW X8(32/64bit) is now supported.

- Fixed bugs -

1. Function of FineCut8 is invalid when clicking the [Move to the Cut Layer] function menu button. (The defect is occurred only CorelDRAW X7.)

[Ver8.5.3 -> Ver8.6]
- Newly functions -

1. Specify Cutting Direction Function
   Cutting direction can be changed after checking cutting direction at CorelDRAW and click pass.
2. Register color/layer of cutting condition as a favorite each
   After registering cutting condition and cutting order which is setting each color and layer as a favorite, apply the favorite, cutting condition and cutting order can be operated simply even though data is changed.
3. Improved the operability of Reverse Cut (Only for CFL-605RT FWVer.1.40 and later）
   First, perform all frame cut at obverse, and continuously perform data cut at reverse.
   To perform separately frame cut and reverse cut in two processes, separated operation of frame and data cutting can be performed at separate timing.

[Ver8.5.2 -> Ver8.5.3]
- Fixed bugs -

1. When using a data which the length is more than 15,400mm, CorelDRAW freezes when displaying plot dialog.
2. When executing printed & cut with RL output, squire pass around the date is printed.

- Improved function -

1. In CFL-605RT, the reverse cut function is improved. (Only for CFL-605RT)To improve the operability of reverse cut, change the UI and specification of reverse cut.
2. Enlarge the area to paint in red around the register mark to prevent occurring the register mark detection error.(Only for the model which has register detection function excluding CF3.)
3. In CJV300/150 series, each line can be cut when performing continuous register cut.But if the data is copied, each line can NOT be cut. (Only for CJV300/150 series)
4. CorelDRAW Technical Suite X7 is supported.

[Ver8.5 -> Ver8.5.2]
- Fixed bugs -
The following bug is fixed:

1. The new information of FineCut8 cannot be acquired through the online information.

[Ver8.4.1 -> Ver8.5]
- Newly Support plotters and CorelDRAW -

1. CFL-605RT is now supported.
2. CorelDRAW X7(32/64bit) is now supported.
3. FineCut8 is enabled to install in the CorelDRAW X6 of CorelDRAW Technical Suite X6 package.
4. Reverse cut function (Supported only for CFL-605RT)
   Use this feature if you need to draw ruled line to the rear face side (surface). Detect a register mark at the surface of printing and cut out the outer frame of register mark, and machine can cut from the reverse side or draw ruled line.

[Ver8.4 -> Ver8.4.1]
- Fixed bugs -

1. When allowing sort function to cut media, machine start cutting from the outside of pass.(CF, CF2, DC, Only CF3 series)

[Ver8.2.1 -> Ver8.4]
- Newly Support plotters and languages -

1. Supported to CJV300, CJV150 series.
2. Supported Simplified Chinese and Traditional Chinese(Only for CorelDRAW X6)

- Improved functions -

1. In CG-SRIII, IP address of plotter is enabled to specify when connecting by LAN.
2. PIN and HLF are deleted from tool of CG-SRIII, and CT6 and CT7 are added for supporting so that the tool which is changed from CG-SRIII have been formally supported.

[Ver8.2.0 -> Ver8.2.1]
- Improved functions -

1. Changed how to set LAN connection to how to select from the connected device list. (Only in CG-SRIII)

- Fixed bugs -

1. The wrong command of intermediate register mark is output to the plotter and the intermediate register mark cannot be detected correctly by the plotter. (Only in CG-SRIII CorelDRAW ver.)

[Ver8.1.2 -> Ver8.2]
- Newly functions -

1. FineCut8 for Illustrator ver8.2 is available for CG-SRIII.
   The following function which is installed on CG-SRIII will be able to use by ver8.2.
   • Intermediate Registration Marks output.
   • Output to a plotter by LAN connection.

[Ver8.1.1 -> Ver8.1.2]
- The following defects occurring at Illustrator CS6 have been improved -

1. It is impossible to output under the language environment except Japanese and English.
2. The letter is partially not displayed.
3. When reading the plot file with open pass by [Import Plot File] function, the unintended lined is displayed. (For CS6-32bit Windows)
4. The defect occurs when setting and applying the output condition.
5. Fixed existing bugs.

[Ver8.1 -> Ver8.1.1]
- Fixed bugs -

1. The error is displayed and the illustrator is shut down unintentionally when trying to start up the illustrator with double-clicking in a state that illustrator is inactive.(For Illustrator CS6(32/64bit) Windows)

[Ver8.0.5 -> Ver8.1]
- Newly Support Illustrator and fixed bugs -

1. Accept Illustrator CS6 (32/64 bit).
2. In Windows8, impossible to install the FineCut8 through a standard user account.
3. When the midpoint of Bezier curve between 2 anchor points exist on a straight-line, an unintended line is cut.

[Ver8.0.1 -> Ver8.0.5]
- Fixed bugs -
The following bug is fixed:

1. The closed figure which consists of two anchor points is not cut.

[Ver8.0 -> Ver8.0.1]
- Fixed bugs -
The following bugs are fixed:

1. "An unexpected error occurred" is displayed when sending data to CF, CF2, DC, CF3(R1/TF2 head) with selecting tools by color or layer.
2. Cutting path is created at 0.1pt(0.035mm) outer side of the frame when the offset value on frame extraction set to 0.

New functions / Improved functions of FineCut8

1. Cutting Start Position Specification
   Specifies the cutting start position.
2. Separating and Cutting Lines(CF/DC/CF2/CF3)
   Avoids cutting too much when cutting thick works including formboard.
3. Online Information
   Notifies the latest information of FineCut including update and announcement.
4. "About FineCut" menu
   You can access to the operation manual quickly from this screen.
5. Illustrator CS5 compatible.
6. Outline Extraction
   Outline data can be created easily on "Trace Simply" screen.
7. "Register Mark Creation" dialog
   An error in reading register marks is avoided by adding the mark for print direction and checking the recommended mark size.
8. Plotter/User Setup
   "Connection test" checks the cause of communication error quickly.

Update procedure

1. Click [start] menu - [All Programs] - [Mimaki FineCut7 for Illustrator]-[Uninstall Mimaki FineCut7 for Illustrator].
2. Double-click and decompress the downloaded file.
3. Double-click the installer file created after decompression.
4. Follow the instruction on screen.
5. When confirmation screen for the old version product CD appears, insert the indicated version CD of the product.
6. After confirming the product CD, follow the instructions on screen.

* For details, see "Readme" created after decompression.

---



Application method



（1）Confirm whether this file suits your product.
（2）If you do not know how to download, see "How To Download."
（3）Click the file name to be downloaded and start download.
* Printing "How To Download" is recommended.
* Be sure to read “Software License Agreement” before download.
